RAKwireless WisBlock Power Supply - UK PLUG

In UK Stock Now!

Description

Power your WisBlock IoT solution with this powerful and reliable USB Type C power supply. Designed for WisBlock, this power supply can be used with the WisBlock Base Boards RAK19001, RAK19003 and RAK19007. It fits as well with the WisBlock Power Modules RAK19012 and RAK19014. It’s 1.2m long cable with the USB Type C connector enables flexible deployment of your WisBlock IoT solution

Features

• Compatible with
  • RAK19001 Dual IO Slot Base Board
  • RAK19003 Mini Base Board
  • RAK19007 Base Board
  • RAK19012 USB LiPo Solar Power Slot Module
  • RAK19014 USB Battery Power Slot Module
• Input: 100-240 V AC (50~60 Hz)
• Output: 5 V DC
• Output current: 3 A
• Power: 15W
• Cable length: 1200 mm
• Connector type: Type-C USB
• Overcurrent protection
• Short circuit protection
• MTBF: ≥ 50000 h (max load at 25 ℃)
• Operating temperature: 0℃ to 40℃
• Storage temperature: -30℃ to +70℃
• Storage humidity: 35~90% RH, Non-condensing
• External dimensions of the power supply: 70x29x39.8 mm (±1 mm)
• EMC compliance: EN55032, EN55013, EN55024, EN55020, FCC Part 15 Class B, GB9254, GB17625.1, EN61000-4-4
